Configurator for Selecting the Right Drum Motor

The form will be forwarded to our drum motor specialist.

Please fill in the information below and click “Send info to specialist” once all required fields are completed.

Based on your inputs, our specialist will contact you and propose a suitable solution for your project. This is a non‑binding offer for you and your company.

Customer information


Physical appearance


Without possible rubber lagging, sprockets or other surfaces

mm
mm
Choose surface
Choose cable glands
mm

The measurement is the material added to the existing diameter; Should include rubber lagging, sprockets etc

mm
Model Crowned [mm] Cylindrical [mm] Min shell length (SL) [mm] (i)
MTS62
ØA = 62,5ØB = 61
 Ø = 61 237 - 263
MTS82
ØA = 81,5ØB = 80,5
 Ø = 81 193 - 320
MTS113
ØA = 113,5ØB = 112
 Ø = 112 230 - 370
MTS138
ØA = 138ØB = 136
 Ø = 136 320 - 410
(i) Depending on gear ratio

Our standard is
MG 2.50 / 6.5
FL 12.5 / 25 / 45

Our standard is
MTS62 - Ø25/SW22
MTS82 - Ø30/SW25
MTS113 - Ø30/SW25
MTS138 -Ø30/SW25

SL=Shell length (Reference length / ordering length)
FW=Face width
EL= Installation length, inside width of conveyor minus 2 mm
AGL=Total length of shaft
MG=Space between shaft flats and endcap
FL=Flat length

Application data


[m/s]
kg
kg
m
mm
kg
kg/m²
N
° (degrees)
°C

Cable and feedback system

m

Why NGI Synchronous Drum Motors?

Benefits for Machine Builders and End Users

  • Dynamic & precise: One motor for everything – from slow-running conveyors to highly dynamic indexing applications.
  • Multispeed dimensioning (wide speed range): Simpler engineering, constant torque, fewer variants, and lower inventory costs.
  • Low energy consumption & high power density: Lower energy and production costs, CO₂ reduction, short ROI, and improved total cost of ownership.
  • Low self-heating: The belt runs cooler, reducing the load on cooling systems.
  • Mechanically precise fit: Custom dimensions – tube diameter, width, and interfaces tailored exactly to your requirements.
  • Compact design: Space‑saving solution, slim machine design, and more usable production space.
  • Maintenance‑free: No unplanned downtime, higher output, and lower operating costs.
  • Robust mechanical design: High reliability, long service life, and fewer failures.
  • Oil‑free and hygienic: Maximum food safety with no risk of contamination – maintenance‑free operation.
  • Certified and documented: IP69K, FDA, UL, and CE approvals confirm the highest hygiene and quality standards.
  • Environmentally friendly: Lower energy consumption, CO₂ reduction, and support for ESG goals.

Let’s Talk About Your Requirements

Installation size, torque, mounting conditions – you define the framework.
We review your data and identify the optimal drum motor model for your application – transparent and non‑binding.

Let’s select the right model together.
