Model SBCX‑C – Belt Scraper with Weight‑Based Angle & Pressure Adjustment and Concentric Mounting

The SBCX‑C uses the same weight‑based, spring‑free mechanism as the SBCX family, controlling scraper angle and cleaning pressure via an external weight arm.

Without an internal spring, the scraper can use a solid shaft, offering a robust and hygienic construction.

The Concentric Mounting (C) centers the scraper around a shared pivot point, ensuring uniform, balanced scraper movement and stable blade contact across the belt.

Key features:

• Spring‑free weight‑based adjustment for precise angle & pressure control
• Concentric Mounting for centered, uniform scraper motion
• Solid‑shaft design for durability and easier cleaning
• Hygienic stainless‑steel construction with smooth, easy‑clean surfaces
• Reliable performance suited for demanding food‑processing lines

Applications:

• Lines requiring centered scraper alignment: Uniform, repeatable cleaning
• Food production environments: High hygiene requirements
• Conveyor systems designed for concentric mounts

Why choose SBCX-C:
A stable, hygienic scraper with concentric mounting and weight‑based adjustment - ideal where uniform movement and simplified mechanics support consistent cleaning results
