Model SBPX‑Q – Belt Scraper with Quick Release Brackets

Plunger Pressure. Fast Pressure Release. Hygienic.

Model SBPX‑Q – Belt Scraper with Plunger and Quick‑Release Brackets

The SBPX‑Q pairs plunger‑controlled adjustable pressure and quick‑pressure‑release with Quick‑Release Brackets (Q) for instant, tool‑free scraper access - ideal for lines that require frequent washdowns or rapid inspections.

After release and re‑engagement, the plunger mechanism restores stable, repeatable cleaning pressure.

Key Features

  • Plunger system for precise, consistent scraper pressure
  • Quick‑pressure‑release for rapid washdowns
  • Quick‑Release Brackets for instant, tool‑free scraper removal
  • Hygienic design with smooth, easy‑clean geometry
  • Strong, reliable construction for high‑frequency sanitation cycles

Applications

  • High‑hygiene production areas: Frequent cleaning cycles
  • Quick‑change lines: Minimize downtime during product changes
  • Food processing & inspection belts: Maintain reliable cleaning with fast access

Why Choose SBPX‑Q
A highly hygienic scraper with instant bracket release and accurate plunger‑controlled pressure - helping you clean faster, reduce downtime, and maintain consistent belt hygiene

  • Technical specifications
  • Download center
Request offer
  • Technical specifications
    *Note: Scraper width must be equal to belt width minus 2 mm as overhang equals excessive wear on the blade and limits lifetime.
    SBNX-Q belt scraper
    Scraper width* SW Min 300 mm
    Scraper to installation surface RH ER 20-100 mm
    Scraper to installation surface EL 20-100 mm
    Installation width IW SW+ER+EL, Maximum 2000 mm
    Conveyor frame thickness CFT 3-18 mm
    Scraper blade size S 81 mm
    Spring force   0-70 N
    Available bracket configuration   B2, B2C, C.
    Specifications

  • Download center
